High Speed Automatic Paper Cup Machine MYC-OC100

Name: High Speed Automatic Paper Cup Machine MYC-OC100
Brand: Mingyuan
SKU: 00019
Rating: 4.1 (60 reviews)

Automatic paper cup machine for sale on China Mingyuan Machinery’s MYC-OC100 is equivalent to a complete machine that integrates paper feeding, sealing, cup bottom feeding, heating, knurling, cup edge curling, discharging, detection, counting, etc.

Send a quote

Specs PDF

Max Speed

95-105pcs/min

Paper Cup Size

2-16 0Z (Mould exchangeable)

Specifications

Model	High Speed Intelligence Model Ultrasonic Paper Cup Machine MYC-OC100
Cup Side Welding	Copper Heater
Cup Side Welding	Ultrasonic heater
Paper Cup Size	2-16 0Z (Mould exchangeable, Max Cup Height:95mm,Max Bottom width:70mm
Rated Speed	95-105pcs/min ( Speed affected by cup size, paper quality & thickness) 90Z,280GSM paper cup Stable running speed 115 pcs each min.
Suitable paper weight	140-350gsm
Raw Material	Only one-side PE coated paper ( Popular for Hot drink cups )
Raw Material	One or Two side PE coated Paper (Popular for Hot and Cold drink Cups)
Suitable paper weight	140-350gsm
Power Source	50/60HZ,380V/220V ( better use 380V.3 Phase )or special Power requirement.
Total Power	5 KW
Total Weight	GW/NW:1800KGS/1750KGS
Pack Size(LWH)	245013601980mm(machinesize)9607002200mm(collecting table size)
Working Air Source	No need provide Air
Working Air Source	Air pressure:0.4Mpa; Air Out-put:0.6m3/minuteNeed to buy Air Compressor(by user)
Cup Bottom Heating	Heater Knurling
Cup Bottom Heating	1side PE paper by heater knurling. 2side PE paper by cool device (circlewater) knurling.
Cup Bottom Knurling	Heater Knurling (if use single PE coated paper)

Customer Case

Country: Saudi Arabia

Solution：MYC-OCM100 Intelligent model paper cup machine

Requirement Size：Single Wall Paper Cup 8oz

Country: Lebanon

Solution：JBZ-OCbucket intellignet model ultrasonic heater paper bucket machine

Requirement Size：850ML ,1100ML and 1500ML

View More Cases

FAQ of Paper Cup Machine

Q:1.How will the machine be repaired if there are faults, andwhat is the warranty?

Our engineer team will send the operation video to guide you tcsolve the problem .if the spare parts is broken in the warrantyperiod, we will send you the new replacement parts for frec.

Q:2.What is the raw materials for the paper cup machine ?

Raw materials : Single /double PE coated paper fan which isalready cut and printed , bottom paper roll

PS: Machine is without printing and cutting function(onlycan cut bottom roll paper, it can not cut the paper fan )

Q:3.One machine is with just one mould or several mould? Can we make difference size of the cup in one machine?

One machine is installed one full set mould for free. You canbuy extra half set mould (easy to change) or full set mould(difficult :1% success rate). We only recommend to change1-3 sets half set mould (with same bottom diameter size)in one machine.

Q:4.What else we need to start the production ?

Food grade or silicone oil and a small air compressor.

Q:5.How can I install the machine and get training servicesin my country?

The machine will be finished installation and tested runningperfectly before the delivery . You will get the completemachine which is finished installation. We will provide the fulloperation and training Videos to guide you to run the machineAnyone can install the machine and operate it easily.

Videos

Through this video, we will show you the paper cup manufacturing processand superior performance of OC100. This machine can produce cupsranging from 2 to 16 ounces, meeting various size requirements.

More videos

Product features

Touch Screen

It adopts PLC controller and touch screen (man -machine interface)all the working parameters can be setup on the control panel whichis convenient for parameter setting and adjusting.(easy operate)

Electric System

Quality Brand electric System like Delta, Schneider.

Sensors

The new design adopts 5 heaters bottom heating system which ismore than the old design and make the paper bottom sealing effectis more better without leakage trouble in high speed running

Moving Cooling Fan

Two cooling fans, two fans can make the paper fan cooling faster. make the cup fan better sealing.

Oil Lubrication And Circulation

The whole machine adopts automatic oil lubrication system( oil circulation system is including oil motor, filter, copper pipe )which makes all gear moving parts working at high speed much moresmoothly and greatly Improve the service life of spare parts .

TEN MOULDS

Newly designed with ten molds for faster and more stable operation.

Integrated Knurling & Curling Motor

The integration of the motor is noteasy to be damaged

Central Shaft

Large and thick central shaft makes machine run stably at high speed without shaking.

FOUR BOTTOM HEATER SYSTEM

ensuring better bottom sealing and preventing leakage issues.
